Compact Ultrafiltration Unit for Home and Industrial Use

Large Image : Compact Ultrafiltration Unit for Home and Industrial Use

Product Details:

Certification:	CE, GS, RoHS, CB, LFGB, UR, EMF, EMC, SASO

Contact Now

Detailed Product Description

Model NO.:	HELLA-CFRO-400/1000	Motive Force:	Electric Power
Style:	Vertical	Performance:	Efficient Filtration
Processing Type:	Ultrafiltration	Core Components:	Filter,Pump,PLC,Sensor,Monitor Device
Core Part Warranty:	More Than 5 Years	Voltage&Phase:	Customized
Power:	Depends On The Model	Video Outgoing-Inspection:	Provided
Machinery Test Report:	Provided	Sevice:	Water Purification Solution
Transport Package:	Woodenbox/Container	Specification:	Customized
Trademark:	Customized	Origin:	Hella, China

Image: Ultrafiltration Flow Chart

1. Raw water system: level control system to adjust stop and start, single-way valve to prevent re-flux.
2. Chemicals system: customized adjustment system to purify different raw water types.

3. Quartz sand filter: remove turbidity, suspended matter, organic matter, colloid and so on.
4. Activated carbon filter: remove free chloride,organics,harmful matter,bad smell/color and so on.
5. PP filter: prevent any deposition of large particles into the UF membrane.
6. UF membrane system: capable of removing over 99% of ions, bacteria, virus, particles.
7. Backwash system: cleaning system to prolong the service life of UF membrane.
8. Sterilization system: UV light and Ozone generator to kill organics like bacteria and virus.

Product Parameter
Output Capacity	100L-1000T/H	Multi-stage Filtration	4/5/6/7-stage
Desalination Rate	≥98%	Filtration Accuracy	up to 0.01
Recovery Rate	≥80%	Machine Material	SS,FRP,CS
Pipe Material	PE,PVC,PPR,SS,CS	Layout	Customized
Power	Depend on the specification	Voltage	Customized
Core Part	Filter,Membrane,Pump	Host Control System	PLC&Terminal Controller
Operating Temp:	3-45	Inlet pressure	0.1-0.5Mpa

HELLA Machine Feature

ΔProduce water continuously 24-7.

ΔEasy operation and maintenance.
ΔIntegrated intelligent electric parts .
ΔAuto-wash to prolong the life service span of filter.

ΔEnviroonmental protection raw macterial
ΔOn-line protection and alarm devices all the time.

Compact Ultrafiltration Unit for Home and Industrial Use 9

Why Be Partner with HELLA Water?

Comprehensive Solutions - Advanced & integrated water filtration systems
Competitive Pricing & High Margins - Helping you grow your business profitably
OEM & Private Labeling Available - Customize with your brand for local market needs
Reliable Quality - ISO-certified systems with durable components & efficient performance
Proven Success in GCC Markets - Reliable systems designed for harsh water conditions
Technical & After-Sales Support - Full training, spare parts, and service assistance
Fast Delivery & Strong Support - On-time shipping with full technical and after-sales assistance
With the rising demand for pure water and integrated purification systems, we believe our cost-effective, high-performance solutions can help you expand your market and drive sales growth.
